17
IP2162EN
EN
Display Description
VC - Setting of closing speed. [cm/s]
N.B.:
24 - Maximum with →
25 - Maximum with → or
40 - Maximum with →
15
Neos Super Fast
25
R2 - Adjustment of thrust on obstacles and current
during opening [%]
The control panel is equipped with a safety device that
stops movement if an obstacle is detected during an
opening operation with disengagement of 10 cm.
00 - Minimum thrust
99 - Maximum thrust
50
R1 - Adjustment of thrust on obstacles and current
during closing [%]
The control panel is fitted with a safety device which
stops or reverses movement when an obstacle is de-
tected during a closing operation.
00 - Minimum thrust
99 - Maximum thrust
50
WARNING: depending on the type of automation and control panel, some menus may
not be available.
i
N.B.: make adjustments gradually and only after performing at least three complete
operations to allow the control panel to be set correctly and detect any friction during
operations.
BA - Basic adjustment
