DITEC E2J User Manual

11
IP1935EN  2010-07-19
11. EXAMPLE APPLICATION FOR GATES WITH ONE SWINGING DOOR WING
FiJ. 11.1
FiJ. 11.3
FiJ. 11.2
When the control panel is used in applications with
one swinJinJ door winJ, one of the followinJ operatinJ
modes ma\ be selected:
(Fig. 11.1) Door wing stops against mechanical
stops and in the event of obstacle detection.
Set an operatinJ time of 2-3 s lonJer than the ef-
fective time taNen b\ the door winJ (TMMAX) and
bridJe terminals 0-11-12 with jumpers.
In this con¿Juration, the door winJ will stop aJainst
mechanical openinJ and closinJ stops and in the
event of obstacle detection.
(Fig. 11.2) Door wing stops against limit switches
and in the event of obstacle detection.
The N.C. contacts of the openinJ and closinJ limit
switches are connected in series with the motor
phases. Set an operation time TMMAX and bridJe
terminals 0-11-12 with jumpers.
In this con¿Juration, the door winJ stops aJainst the
openinJ and closinJ limit switches and in the event
of obstacle detection.
(Fig. 11.3) Door wing stops against limit switches
and inverts in the event of obstacle detection.
Set an operatinJ time TM=MAX and connect the
openinJ and closinJ limit switches N.C. contacts to
terminals 0-11-12.
In this con¿Juration, the door winJ stops when the
limit switches are activated. In the event of obstacle
detection while openinJ, the door winJ stops, perfor-
minJ a disenJaJement operation, whereas durinJ
a closin
J operation, the door winJ reopens.
R1 TM
15 13 12 11 0 1 15689
A
B
ON
OFF
123 4
ON
OFF
123 4 5 6
R1<MAX
TM<MAX
DIP3B=OFF
R1 TM
15 13 12 11 0 1 15689
A
B
ON
OFF
123 4
ON
OFF
123 4 5 6
R1<MAX
TM=MAX
DIP3B=OFF
Opening limit switch
Closing limit switch
R1 TM
15 13 12 11 0 1 15689
A
B
ON
OFF
123 4
ON
OFF
123 4 5 6
R1<MAX
TM<MAX
DIP3B=OFF
UWV
230V~
com
Motor 1
Limit switch
(230V - 5A)
