(Fig. 11.4) Door wing stops against mechanical stops
and inverts in the event of obstacle detection.
Set an operatinJ time of 2-3 s lonJer than the ef-
fective time taNen b\ the door winJ (TMMAX) and
position the proximit\ limit switches 2-3 s ahead of
the mechanical stop.
In this con¿Juration, the door winJ stops aJainst its
respective mechanical closinJ and openinJ stop.
In the event of obstacle detection before the acti-
vation of the proximit\ limit switch while openinJ,
the door winJ stops, performinJ a disenJaJement
operation; after the proximit\ limit switch is activated,
the door winJ stops aJainst the obstacle.
In the event of obstacle detection while closinJ and
before the activation of the proximit\ limit switch,
the door winJ reopens; after the proximit\ limit
switch is activated, the door winJ stops aJainst the
obstacle.
(Fig. 11.5) Door wing stops against the limit switch
when opening and against the mechanical stop
when closing, and inverts in the event of obstacle
detection.
Set an operatinJ time 2-3 s lonJer than the effective
time taNen b\ the door winJ (TMMAX), and the
closinJ proximit\ switch 2-3 s earlier than the mecha-
nical stop and connect the N.C. openinJ limit switch
in series to the openinJ phase of the motor.
In this con¿Juration the winJ
stops on the closinJ
mechanical stop while on the openinJ, it stops and
releases when the relative limit switch operates.
DurinJ openinJ operation, in the event of obstacle
detection, the winJ stops, performinJ a disenJaJe-
ment operation.
DurinJ closinJ operation, in the event of obstacle
detection before the proximit\ switch operates, the
winJ reopens; after the proximit\ switch operates,
the winJ stops on the closinJ mechanical stop.
FiJ. 11.4
R1 TM
15 13 12 11 0 1 15689
A
B
ON
OFF
123 4
ON
OFF
123 4 5 6
R1<MAX
TM<MAX
DIP3B=OFF
Opening proximity switch
Closing proximity switch
FiJ. 11.5
R1 TM
15 13 12 11 0 1 15689
A
B
ON
OFF
123 4
ON
OFF
123 4 5 6
R1<MAX
TM<MAX
DIP3B=OFF
UWV
230V~
com
Motor 1
Opening
limit switch
(230V - 5A)
Closing proximity switch
