13
IP1935EN 2010-07-19
12. EXAMPLE APPLICATION FOR GATES WITH TWO SWINGING DOOR WINGS
FiJ. 12.1
FiJ. 12.3
FiJ. 12.2
When the control panel is used in applications with two
overlappinJ swinJinJ door winJs, one of the followinJ
operatinJ modes ma\ be selected:
(Fig. 12.1) Door wings stop against mechanical
stops and in the event of obstacle detection.
Set an operatinJ time of 2-3 s lonJer than the ef-
fective time taNen b\ the door winJs (TMMAX) and
bridJe terminals 0-11-12 with jumpers.
In this con¿Juration, each door winJ will stop aJainst
mechanical openinJ and closinJ stops and in the
event of obstacle detection.
(Fig. 12.2) Door wings stop against limit switches
and in the event of obstacle detection.
The N.C. contacts of the openinJ and closinJ limit
switches are connected in series with the motor
phases. Set an operatinJ time TMMAX and bridJe
terminals 0-11-12 with jumpers.
In this con¿Juration, each door winJ will stop aJainst
the openinJ and closinJ limit switches and in the
event of obstacle detection.
(Fig. 12.3) Door wings stop against limit switches
and invert in the event of obstacle detection.
Set an operatinJ time TM=MAX and connect the clo-
sinJ limit switch N.C. contacts to terminals 0-11-12
and the openinJ limit switch N.C. contacts in series
with the open phase of each motor.
In this con¿Juration, each door winJ stops when the
limit switches are activated.
In the event of obstacle detection while openinJ, onl\
the door winJ that detects the obstacle stops, perfor-
min
J a disenJaJement operation, whereas durinJ a
closinJ operation, both door winJs reopen.
TR R1 TM
15 13 12 11 0 1 15689
TR>3 s
R1<MAX
TM<MAX
15 13 12 11 0 1 15689
UWV
230V~
com
Motor 1
230V~
com
Motor 2
Limit switch
(230V - 5A)
TR R1 TM
TR>3 s
R1<MAX
TM<MAX
XZY
15 13 12 11 0 1 15689
UWV
230V~
com
Motor 1
230V~
com
Motor 2
Opening limit switch
(230V - 5A)
Closing limit switch
Closing limit switch
TR R1
TR>3 s
R1<MAX
TM=MAX
XZY
TM
