1.2 General Information
The HA8-LP Operator is a complete swinging door solution for push, pull, surface applied installations. The header contains
the Driving system (Motor), Torque production (Gearbox), and a Control system to interlink the two.
The HA8-LP Operator ensures all-around safety. It can be combined with the full range of safety units, such as presence
and motion sensors. It is easy to install for both new construction and retrofit applications.
• All wiring must conform to standard wiring practice in accordance with national and local wiring codes.
• Door must swing freely through the entire opening and closing cycle before beginning of installation.
Typically, doors are hung on hinges 5” (127mm) maximum width or 3/4” (19mm) offset pivots.
• An incorrectly installed or improperly adjusted door operator can cause property damage or personal injury.
These instructions should be followed to avoid the possibility of misapplication or maladjustment.
• All dimensions are given in inches (millimeters), unless otherwise noted.
Door/Frame Preparation
• Before installation, verify door frame is properly reinforced and is well anchored in the wall.
• Concealed electrical conduit, and concealed switch or sensor wires should be pulled to the frame before proceeding.
Suggested Fasteners for Frame
• #14 x 2-3/4” (70mm) long sheet metal screws.
Suggested Fasteners for Door
• #12, #14, Wood screws, Sheet Metal screws, Self-tapping screws of varying lengths depending on applications.
The fastener components listed above are merely suggestions. A technician should use their best
discretion to determine what components they’ll need to complete the job.
Do Not use Drywall Screws or Hollow Wall Anchors to mount the Back Plate / Header.
Shipping inspection
Verify that the order was shipped complete and correct, including model number, door handing, color, and header width.
• If any of the above items are not correct, do not attempt to install until all conditions are correct
• Report any incorrect items to the general contractor immediately.
NO CLAIMS FOR SHORTAGES WILL BE ALLOWED UNLESS REPORTED
WITHIN 24 HOURS OF RECEIPT OF SHIPMENT.
Safety Precautions
• Do not climb or put weight on any door or header parts
• Do not let children play with the operator or the electrical board
• Keep remote controls away from children
• Keep all power off to the unit, when performing any work or maintenance
To avoid bodily injury, material damage and malfunction of the product, the instructions contained in this manual must be
strictly observed during installation, adjustment, repairs and service etc. Training is needed to carry out these tasks safely.
Only Entrematic-trained technicians should be allowed to carry out these operations.
