1.0 BEFORE INSTALLATION
Compliance Codes and Standards
The operator complies with the following codes and standards:
• UL STD.325 & ANSI/BHMA STD. A156.19; Fire rated UL STD. 10 (b); UL STD. 10(c); NFPA STD. 252
• CAN/CSA STD. C22.2 NO. 247 & CAN/ULC STD. S104
• Under No Circumstances shall the Certification Label of the HA8 operator be tampered, modified
or removed!
• It is the responsibility of the final installer and/or installation company, to certify that the final
completed operator is installed in accordance with local building codes and applicable laws.
1.3 Technical Specifications & Required Tools
1/8 hp, 16VDC, 3A (Standard)
Continuous opening and closing cycles
Manual Opening/Closing Force
- during power failure
Opening Force: 15 lbs; Closing Force: 25lbs
Door Opening/Closing Speed & Force
Adjustable, see section 10.0 ADA ADJUSTMENTS
Operation - during power failure
Low resistance when opened by hand. Door closes by spring.
Pulsed Energy to Motor. No overheating. Continuous hold open
Ambient temperature -4F to +120F (-20C to +50C) No condensation or icing
Ambient humidity 30% to 85% RH
(No hazardous materials must be present in the atmosphere)
Required Tools for installation:
• Screwdrivers: Flat, Philip, 5/16” Hex. Nut
• Power Drill and Drill Bits
• Additional Fasteners Depending Surface
