Basic functions
25
Basic functions
Indicators for body temperature
The thermometer has a backlight, which im-
mediately illuminates in different colors after
measuring your body temperature indicating
the range of your body temperature.
Green backlight:
The body temperature measured is below
37.5 °C (99.5 °F).
Red backlight:
The body temperature measured is within the
range of an elevated temperature of 37.5 °C
(99.5 °F) to 37.9 °C (100.3 °F).
Red backlight and additionally FE (fever) on
the LCD display:
The body temperature measured is within the
fever range between 38.0 °C (100.4 °F) and
42.9 °C (109.3 °F).
Backlight/flashlight function
Backlight:
Each time the SET
3
or MEM
9
button is
pushed, the backlight
2
of the LCD display
will activate for approx. 10 seconds.
Flashlight:
Pushing the button (
)
8
for approx. 2 seconds
in standby mode, the flashlight
12
of the ther-
mometer (1LED next to the probe tip) will illumi-
nate for approx. 10 seconds. At the same time,
