1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 16 di 39
A19 Condenser
water flow
alarm
Enabled if AL32≠0.
If CO26≠0:
digital input active for AL30;
the alarm is disabled for AL04 starting from
the start-up of the condenser pump.
If CO26=0:
digital input active for AL30.
Alarm relay/ open
collector ON.
Buzzer ON.
General alarm icon
lighted .
Flashing “Flow!” icon.
Code on display.
If the unit is in std-by
or OFF the icon is on
to indicate the the real
state of the pump and
the flow switch.
Automatic
D
igital input not active
for AL31.
It turns to manual if
the digital inpuct is
active for AL29.
Manual
Digital input not active
for AL31 and proceed
with manual reset.
A20 Condenser
water pump
maintenance
alarm
Operating hours > CO28 Alarm relay/ open
collector ON.
Buzzer ON.
General alarm icon
lighted.
Code on display.
Manual
Reset operating
hours, point 13.6
rtC Clock alarm Need to set the clock time Open collector / alarm
relay ON
Buzzer ON
General alarm icon
lighted
Alarm code on display
Manual:
Set the clock and then
proceed with manual
reset.
rtF Clock alarm Faulty clock control Open collector / alarm
relay ON
Buzzer ON
General alarm icon
lighted
Alarm code on display
Manual:
Proceed with manual
reset, if nothing
happens change the
clock.
EE EEPROM
error alarm
Possible data losing Open collector / alarm
relay ON
Buzzer ON
General alarm icon
lighted
Alarm code on display
Manual:
Proceed with manual
reset., if nothing
happens the controller
is locked, no
regulation available.
ACF1 Configuration
alarm
Heat pump configured without reversing valve Open collector / alarm
relay ON
Buzzer ON
General alarm icon
lighted
Alarm code on display
Automatic
After parameter
proper debug.
