IC100CX
1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 24 di 39
CF05 Pb2 configuration
0= Probe not enabled
1= NTC temperature of evaporator outlet
2= Digital Input for antifreeze alarm
3= Digital input for heating demand
0 3
CF06 Pb3 configuration
0= Probe not enabled
1= NTC temperature condensing control
2= 4..20mA for condensing pressure
3= 4..20ma for Dynamic Set point
4= NTC temperature for anti freeze alarm (water/water)
5= NTC high temperature probe of system inlet water
6= 0..5V for condensing pressure
0 6
CF07 Pb4 configuration
0= Probe not enabled
1= NTC condensing control
2= Multifunction digital input
3= External air temperature
4= NTC temperature for anti freeze alarm (water/water)
5= NTC temperature for combined defrost
6= NTC temperature for logging
6= NTC condenser outlet temperature (water/water units
whith reversal on water circuit)
7= NTC high temperature probe of system inlet water
0 7
CF08 ID1 configuration
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Evaporator flow switch alarm
3= Remote On/off
4= Remote Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
10= 1
st
and 2
nd
compressor thermal protection
11= General alarm (unit shutdown)
12= Evaporator water pump thermal protection alarm/
supply fan thermal protection alarm
13= Condenser water pump thermal protection alarm
14= Condenser flow switch alarm
15= not used
0 15
