dixell iCHiLL 100CX User Manual

IC100CX
1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 25 di 39
CF09 ID2 configuration
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Evaporator flow switch alarm
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
10= 1
st
and 2
nd
compressor thermal protection
11= General alarm for total unit shutdown
12= Evaporator water pump thermal protection alarm/
supply fan thermal protection alarm
13= Condenser water pump thermal protection alarm
14= Condenser flow switch alarm
15= not used
0 15
CF10 ID5 configuration
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Evaporator flow switch alarm
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
10= 1
st
and 2
nd
compressor thermal protection
11= General alarm for total unit shutdown
12= Evaporator water pump thermal protection alarm/
supply fan thermal protection alarm
13= Condenser water pump thermal protection alarm
14= Condenser flow switch alarm
15= not used
0 15
