1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 26 di 39
CF11 Pb4 configuration in digital input mode
0= 1
st
compressor thermal protection
1= Condenser fan thermal protection
2= Evaporator flow switch alarm
3= Remote On/off
4= Cooling/Heating
5= 2
nd
compressor thermal protection
6= 2
nd
compressor or step request (Motocondensing unit)
7= End defrost
8= Energy Saving
9= Anti Freeze alarm
10= 1
st
and 2
nd
compressor thermal protection
11= General alarm for total unit shutdown
12= Evaporator water pump thermal protection alarm/
supply fan thermal protection alarm
13= Condenser water pump thermal protection alarm
14= Condenser flow switch alarm
15= not used
0 15
CF12 ID1 input polarity
0= active for closed contact
1= active for open contact
0 1
CF13 ID2 input polarity
0= active for closed contact
1= active for open contact
0 1
CF14 ID3 input polarity
0= active for closed contact
1= active for open contact
0 1
CF15 ID4 input polarity
0= active for closed contact
1= active for open contact
0 1
CF16 ID5 input polarity
0= active for closed contact
1= active for open contact
0 1
CF17 Pb1 input polarity
0= active for closed contact
1= active for open contact
0 1
CF18 Pb2 input polarity
0= active for closed contact
1= active for open contact
0 1
CF19 Pb4 input polarity
0= active for closed contact
1= active for open contact
0 1
