DJI FPV
User Manual
27
© 2021 DJI All Rights Reserved.
The charging time is approximately 50 minutes.
It is recommended to discharge the Intelligent Flight Batteries to 30% or lower. This can be done by
ying the aircraft outdoors until there is less than 30% charge left.
DO NOT charge an Intelligent Flight Battery immediately after ight as the temperature may be too
high. Wait until it cools down to room temperature before charging again.
The charger stops charging the battery if the battery cell temperature is not within the operating range
of 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F (22° to 28° C).
The Battery Charging Hub (not included) can charge up to three batteries. Visit the ocial DJI online
store for more information about the Battery Charging Hub.
Fully charge the battery at least once every three months to maintain battery health.
DJI does not take any responsibility for damage caused by third-party chargers.
The table below shows the battery level during charging.
LED1 LED2 LED3 LED4 Battery Level
0% < Battery Level ≤ 50%
50% < Battery Level ≤ 75%
75% < Battery Level < 100%
Fully Charged
Battery Protection Mechanisms
The battery level LEDs can display battery protection notications triggered by abnormal charging conditions.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern Status
LED2 blinks twice per second Overcurrent detected
LED2 blinks three times per second Short circuit detected
LED3 blinks twice per second Overcharge detected
LED3 blinks three times per second Over-voltage charger detected
LED4 blinks twice per second Charging temperature is too low
LED4 blinks three times per second Charging temperature is too high
3. The battery level LEDs display the current battery level during charging.
4. The Intelligent Flight Battery is fully charged when all the battery level LEDs are o. Detach the charger when
the battery is fully charged.
