Flight
Route
Include Center
Line
Recommended to be enabled.
Altitude Mode
Relative to takeoff point (ALT) by default
Flight Route
Altitude
50~100 meters is recommended; maximum 150
meters
Target Surface to
Takeoff point
0 by default
Speed
Flight speed can be adjusted according to the
desired point cloud density. 8–12 m/s is
recommended.
IMU Calibration
Enabled
Photo Mode
Timed Interval Shot
Flight
Route-
Advanced
Settings
Side Overlap
Recommended to be at least 50%.
3.4.3 Powerline
L1 can be used to collect the point cloud data of transmission lines and the power pylons. As there are
undulations in the power line corridor, the recommended workflow is to use the “Live Mission Record”
function to create a waypoint flight mission so that we can fly with variable heights.
