Product Profile
8
©
2016 DJI. All Rights Reserved.
Mavic Pro
User Manual
Aircraft Diagram
Remote Controller Diagram
1
.
GPS
2
.
Propeller
3
.
Motor
4
.
Front LED Indicator
5
.
Forward Vision System
6
.
Antennas
7
.
Gimbal and Camera
8
.
Intelligent Flight Battery
9
.
Link Button
10
.
Linking Status Indicator
11
.
Camera Micro SD Card Slot
12
.
Control Mode Switch
13
.
Micro USB Port
14
.
Aircraft Status Indicators
15
.
Downward Vision System
1
2
3
4
5
6
7
8
12
11
13
1514
10
9
1
3
5
4
2
8
9
6
7
1. Antennas
Relays aircraft control and video
signal.
2. Return Home (RTH) Button
Press and hold the button to initiate
Return to Home (RTH). Press once
again to cancel RTH.
3. Power Button
Used to turn the remote controller on
and off.
4. Control Stick
Controls the orientation and
movement of the aircraft.
