dji MIC MINI - Product Profile; Transmitter

1 Product Prole
1.1 Transmitter
1
4
2
3
1. System Status LED
Battery Level
Solid red 0-10%
Solid green/blue
*
> 10%
Link Status with the Receiver
Solid green Linked with the receiver
Blinks green slowly Not linked with the receiver
Blinks blue and green alternately Linking
Bluetooth Link Status
Solid blue Linked with a Bluetooth device
Blinks blue slowly No Bluetooth device linked
Blinks blue and green alternately Linking
Battery Level During Charging
*
Blinks green/blue slowly 0-25%
× 2
Blinks green/blue twice 26-50%
× 3
Blinks green/blue three times 51-75%
× 4
Blinks green/blue four times 76-100%
O Fully charged
Firmware Update
DJI Mic Mini User Manual
© 2024 DJI All Rights Reserved. 5
