dji Mini 2 User Manual

16
©
2021 DJI All Rights Reserved.
DJI Mini 2 User Manual
Detection Fields
The Downward Vision System works best when the aircraft is at an altitude of 0.5 to 10 m and its
operating range is 0.5 to 30 m.
Infrared Sensing System
Downward Vision System
Landing Protection
Landing Protection will activate during Smart RTH.
1. During Landing Protection, the aircraft will automatically detect and carefully land on suitable ground.
2. If the ground is determined unsuitable for landing, DJI Mini 2 will hover and wait for pilot conrmation.
3. If Landing Protection is not operational, DJI Fly will display a landing prompt when the aircraft
descends below 0.5 m. Tap conrm or pull down on the throttle stick to land.
Vision System and Infrared Sensing System
DJI Mini 2 is equipped with a Downward Vision System and Infrared Sensing System. The Downward
Vision System consists of one camera and the Infrared Sensing System consists of two 3D infrared
modules. The Downward Vision System and Infrared Sensing System helps the aircraft maintain its
current position, hover in place more precisely, and to y indoors or in other environments where GPS is
unavailable.
If the aircraft is at an altitude of 65 ft (20 m) or higher and has not yet reached the RTH altitude, the
throttle stick can be moved to stop the aircraft from ascending and the aircraft will y to the Home
Point at its current altitude (only available with rmware v1.0.0.0. This function is not available when
the rmware is updated to v1.1.0.0 or later).
During RTH, the speed, altitude, and orientation of the aircraft can be controlled using the remote
controller if the remote controller signal is normal. However, the remote controller cannot be used to
pan left or right. When the aircraft is ascending or ying forward, the user can push the control stick
completely in the opposite direction to make the aircraft hover in place.
GEO zones will aect RTH. If the aircraft ies into a GEO zone during RTH, it will either descend until it
exits the GEO zone and continue to y to the Home Point or hover in place due to altitude limits.
The aircraft may not be able to return to a Home Point when the wind speed is too high. Fly with
caution.
71°
56°

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
