dji Mini 2 User Manual

28
©
2021 DJI All Rights Reserved.
Remote Controller
Remote Controller Profile
DJI Mini 2 comes equipped with the DJI RC-N1 remote controller, which boasts DJI’s long-range OcuSync
2.0 transmission technology, offering a maximum transmission range of 6 mi (10 km) and 720p when
displaying video from the aircraft to DJI Fly on your mobile device. Easily control the aircraft and camera
using the onboard buttons. The detachable control sticks make the remote controller easier to store.
In a wide-open area with no electromagnetic interference, OcuSync 2.0 smoothly transmits video links
at up to 720p. The remote controller works at both 2.4 GHz and 5.8 GHz, and will automatically select
the best transmission channel.
OcuSync 2.0 reduces latency to approx. 200 ms by improving the camera performance through the
video decoding algorithm and the wireless link.
The built-in battery has a capacity of 5200 mAh and a maximum run time of 6 hours. The remote
controller charges the mobile device with a charging ability of 500mA@5V. The remote controller
automatically charges Android devices. For iOS devices, first make sure that charging is enabled in
DJI Fly. Charging for iOS devices is disabled by default and needs to be enabled each time the remote
controller is powered on.
Compliance Version: The remote controller is compliant with local regulations.
Control Stick Mode: The control stick mode determines the function of each control stick movement.
Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can
be congured in DJI Fly. The default mode is Mode 2.
Using the Remote Controller
Powering On/O
Press the power button once to check the current battery level. If the battery level is too low, recharge
before use.
Press once, then press again and hold to power the remote controller on or o.
Charging the Battery
Use a USB-C cable to connect the USB charger to the USB-C port of the remote controller. It takes
approx. four hours to fully charge the remote controller.
Controlling the Gimbal and Camera
1. Shutter/Record Button: press once to take a photo or to start or stop recording.
2. Photo/Video Toggle: press once to switch between photo and video mode.

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
