dji Mini 2 User Manual

6
©
2021 DJI All Rights Reserved.
Product Prole
Introduction
DJI Mini 2 boasts a foldable design and an ultralight weight of less than 249 g. Featuring a Downward
Vision System and Infrared Sensing System, DJI Mini 2 can hover and y indoors as well as outdoors
and automatically initiate Return to Home (RTH). With a fully stabilized 3-axis gimbal and 1/2.3”
sensor camera, DJI Mini 2 shoots 4K video and 12MP photos. Enjoy Intelligent Flight modes such as
QuickShots and Panorama, while QuickTransfer and Trimmed Download make downloading and editing
photos and videos more convenient and ecient.
DJI Mini 2 comes equipped with the DJI RC-N1 remote controller, which boasts DJI’s long-range
transmission OCUSYNC
TM
2.0 technology, oering a maximum transmission range of 6 mi (10 km) and
video quality of up to 720p from the aircraft to the DJI Fly app on a mobile device. The remote controller
works at both 2.4 GHz and 5.8 GHz, and is capable of selecting the best transmission channel
automatically without latency. The aircraft and camera can easily be controlled using the onboard
buttons.
DJI Mini 2 has a maximum ight speed of 36 mph (57.6 kph) and a maximum ight time of 31 minutes,
while the maximum runtime of the remote controller is six hours.
Preparing the Aircraft
All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the aircraft.
1. Remove the propeller holder.
2. Remove the gimbal protector from the camera.
3. In the following order, unfold the front arms, rear arms, and all the propellers.
Maximum ight time was tested in an environment with no wind while ying at a consistent 10.5 mph
(17 kph) and the maximum ight speed was tested at sea level altitude with no wind. These values
are for reference only.
The remote controller reaches its maximum transmission distance (FCC) in a wide-open area with
no electromagnetic interference at an altitude of approx. 400 ft (120 m). The maximum transmission
distance refers to the maximum distance that the aircraft can still send and receive transmissions. It
does not refer to the maximum distance the aircraft can y in a single ight. The maximum runtime
was tested in a laboratory environment and without charging the mobile device. This value is for
reference only.
5.8 GHz is not supported in some regions. This frequency band will automatically be disabled in
these regions. Observe local laws and regulations.

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
