DJI Mini 2 User Manual
Calibrating the Compass
It is recommended to calibrate the compass in the following situations when ying outdoors:
1. Flying at a location further than 31 miles (50 km) away from the location the aircraft was last own.
2. The aircraft has not been own for more than 30 days.
3. A compass interference warning appears in DJI Fly and/or the aircraft status indicator blinks red and
yellow alternatively.
DO NOT calibrate the compass in locations where magnetic interference may occur such as close
to magnetite deposits or large metallic structures such as parking structures, steel reinforced
basements, bridges, cars, or scaolding.
DO NOT carry objects that contain ferromagnetic materials such as mobile phones near the aircraft
during calibration.
It is not necessary to calibrate the compass when ying indoors.
Calibration Procedure
Choose an open area to carry out the following procedure.
1. Tap System Settings in DJI Fly, select Safety, then Calibrate, and follow the on-screen instructions.
The aircraft status indicator is solid yellow, indicating calibration has started.
2. Hold the aircraft horizontally and rotate it 360°. The aircraft status indicator will turn solid green.
3. Hold the aircraft vertically and rotate it 360° around a vertical axis.
4. If the aircraft status indicator blinks red, the calibration has failed. Change your location and try the
calibration procedure again.
Aircraft takeo weight includes battery, propellers, and a microSD card.
Aircraft registration is required in some countries and regions. Check local rules and regulations
before use.
The transmission distance in common scenarios listed above are the typical values tested in an FCC
area without obstruction.
These specications have been determined through tests conducted with the latest rmware. Firmware
updates can enhance performance. It is highly recommended to update to the latest rmware.
Recommended microSD Cards
16 GB: SanDisk Extreme
32 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Industrial,
SanDisk Extreme V30 A1, SanDisk Extreme V30 A2, SanDisk Extreme Pro
V30 A1, SanDisk Extreme Pro V30 A2, Lexar 633x, Lexar 667x
64 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Extreme
V30 A1, SanDisk Extreme V30 A2, Lexar 633x, Lexar 667x, Lexar 1000x,
Lexar High Endurance, Toshiba EXCERIA M303 V30 A1, Netac Pro V30 A1
128 GB: Samsung Pro Plus, Samsung Evo Plus, SanDisk Extreme V30
A1, SanDisk Extreme V30 A2, SanDisk Extreme Plus V30 A1, SanDisk
Extreme Plus V30 A2, Lexar 633x, Lexar 667x, Lexar 1000x, Lexar High
Endurance, Toshiba EXCERIA M303 V30 A1, Netac Pro V30 A1
256 GB: SanDisk Extreme V30 A1, SanDisk Extreme V30 A2

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
