dji Mini 2 User Manual

©
2021 DJI All Rights Reserved.
47
DJI Mini 2 User Manual
Transmitter Power (EIRP) 2.4 GHz: ≤26 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: ≤26 dBm (FCC/SRRC), ≤14 dBm (CE)
Battery Capacity 5200 mAh
Operating Current/Voltage 1200 mA@3.6 V (with Android device)
700 mA@3.6 V (with iOS device)
Supported Mobile Device Size 180×86×10 mm (Height×Width×Thickness)
Supported USB Port Types Lightning, Micro USB (Type-B), USB-C
Video Transmission System OcuSync 2.0
Live View Quality 720p@30fps
Max Bitrate 8 Mbps
Latency (depending on
environment and mobile device)
200 ms
Charger
Input 100-240 V, 50/60 Hz, 0.5 A
Output 12V 1.5A / 9V 2A / 5V 3A
Rated Power 18 W
Intelligent Flight Battery (International Version)
Battery Capacity 2250 mAh
Voltage 7.7 V
Charging Voltage Limit 8.8 V
Battery Type LiPo 2S
Energy 17.32 Wh
Weight 82.5 g
Charging Environment
Temperature
5° to 40° C (41° to 104° F)
Max Charging Power 29 W
Intelligent Flight Battery (JP version)
Battery Capacity 1065 mAh
Voltage 7.6 V
Charging Voltage Limit 8.7 V
Battery Type LiPo 2S
Energy 8.09 Wh
Weight 48.9 g
Charging Environment
Temperature
5° to 40° C (41° to 104° F)
Max Charging Power 18 W
App
App DJI Fly
Required Operating System iOS v11.0 or later; Android v6.0 or later
SD Cards
Supported SD Cards UHS-I Speed Grade 3 rating or above microSD card

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
