dji Mini 2 User Manual

18
©
2021 DJI All Rights Reserved.
DJI Mini 2 User Manual
Intelligent Flight Mode
QuickShots
QuickShot shooting modes include Dronie, Rocket, Circle, Helix, and Boomerang. DJI Mini 2 records
according to the selected shooting mode and automatically generates a short video. The video can be
viewed, edited, or shared to social media from playback.
Dronie: The aircraft ies backward and ascends with the camera locked on the subject.
Rocket: The aircraft ascends with the camera pointing downward.
Circle: The aircraft circles around the subject.
Helix: The aircraft ascends and spirals around the subject.
Boomerang: The aircraft ies around the subject in an oval path, ascending as it ies away from
its starting point and descending as it ies back. The starting point of the aircraft forms one end of
the long axis of the oval, while the other end of its long axis is at the opposite side of the subject
from the starting point. Make sure there is sucient space when using Boomerang. Allow a radius
of at least 99 ft (30 m) around the aircraft and allow at least 33 ft (10 m) above the aircraft.
Using QuickShots
1. Make sure that the Intelligent Flight Battery is suciently charged. Take o and hover at least 6.6 ft (2 m)
above the ground.
2 m
Keep the sensors clean at all times. DO NOT tamper with the sensors. DO NOT use the aircraft in
environment with dust and humidity. DO NOT obstruct the Infrared Sensing System.
DO NOT y when it is rainy, smoggy, or if there is no clear sight.
Check the following every time before takeo:
a) Make sure there are no stickers or any other obstructions over the Infrared Sensing System or
Downward Vision System.
b) If there is any dirt, dust, or water on the Infrared Sensing System or Downward Vision System,
clean with a soft cloth. DO NOT use any cleanser that contains alcohol.
c) Contact DJI Support if there is any damage to the glass of the Infrared Sensing System or
Downward Vision System.

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
