dji Mini 2 User Manual

©
2021 DJI All Rights Reserved.
49
DJI Mini 2 User Manual
If the aircraft status indicator blinks red and yellow alternatively after calibration is completed, this
indicates that the current location is not suitable for ying the aircraft due to the level of magnetic
interference. Choose a new location.
A prompt will appear in DJI Fly if compass calibration is required before takeo.
The aircraft can take o immediately once calibration is complete. If you wait more than three
minutes to take o after calibration, you may need to calibrate again.
Updating Firmware
When you connect the aircraft or remote controller to DJI Fly, you will be notified if a new firmware
update is available. To update, connect the mobile device to the internet and follow the on-screen
instructions. Note that the firmware cannot be updated if the remote controller is not linked to the
aircraft.
Make sure to follow all the steps to update rmware. Otherwise, the update may fail. The aircraft will
power o automatically after the rmware update is complete.
The rmware update will take approx. 10 minutes. It is normal for the gimbal to go limp, aircraft
status indicators to blink, and the aircraft to reboot. Wait patiently until the update is complete.
Before performing an update, make sure the Intelligent Flight Battery is at least 15% charged and the
remote controller is at least 20% charged.
The remote controller may become unlinked from the aircraft after updating. Relink the remote
controller and aircraft. Note that the update may reset various main controller settings, such as the
RTH altitude and the maximum ight distance, to default settings. Before updating, take note of your
preferred DJI Fly settings and readjust them after the update.
After-Sales Information
Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and
support.

dji Mini 2 Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	5 m/s
Frequency band	2.4 - 5.8 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Maximum flight time	31 min
Maximum descent speed	3.5 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.5 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	130 °/sec
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1 / 8000 s
Supported video modes	1080p, 1520p, 2160p
Image formats supported	JPEG, RAW
Video formats supported	AVC, H.264, MP4, MPEG4, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Maximum device width	92 mm
Battery voltage	7.7 V
Battery capacity	2250 mAh
Transmitter battery capacity	5200 mAh
AC adapter power	18 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.5 A
Power consumption (transmitter) (max)	1200 mA
Operating temperature (T-T)	10 - 40 °C
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	290 mm
Width	245 mm
Height	55 mm
Weight	249 g
Battery weight	86.2 g
Wheelbase diagonal	213 mm
