DJI Mini 3
User Manual
9
©
2022 DJI All Rights Reserved.
DJI RC Remote Controller
1
6
11
16
2
7
12
17
3
8
13
18
4
9
14
5
10
15
11. Gimbal Dial
Controls the tilt of the camera.
12. Record Button
Press once to start or stop recording.
13. Camera Control Dial
For zoom control.
14. Focus/Shutter Button
Press halfway down on the button to auto
focus and press all the way down to take
a photo.
15. Speaker
Outputs sound.
16. Control Sticks Storage Slot
For storing the control sticks.
17. Customizable C2 Button
Switch between landscape mode and
portrait mode. The function can be set in
DJI Fly.
18. Customizable C1 Button
Switch between recentering the gimbal
and pointing the gimbal downward. The
function can be set in DJI Fly.
1. Control Sticks
Use the control sticks to control the
movement of the aircraft. The control
sticks are removable and easy to store.
Set the flight control mode in DJI Fly.
2. Status LED
Indicates the status of the remote
controller.
3. Battery Level LEDs
Displays the current battery level of the
remote controller.
4. Flight Pause/Return to Home (RTH) Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
System is available). Press and hold to
initiate RTH. Press again to cancel RTH.
5. Flight Mode Switch
Switch between Cine, Normal, and Sport
mode.
6. Power Button
Press once to check the current battery
level. Press, and then press and hold to
power the remote controller on or off.
When the remote controller is powered
on, press once to turn the touchscreen on
or off.
7. Touchscreen
Touch the screen to operate the remote
controller. Note that the touchscreen is
not waterproof. Operate with caution.
8. USB-C Port
For charging and connecting the remote
controller to your computer.
9. microSD Card Slot
For inserting a microSD card.
10. USB-C Connector
For connecting a USB-C headphone.

Other manuals for dji Mini 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Mini 3 and is the answer not in the manual?

dji Mini 3 Specifications

General IconGeneral
TypeQuadcopter
FoldableYes
CertificationFCC
Product colorGray
Construction typeReady-to-fly (RTF)
Maximum speed10.55 m/s
Number of axis3
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors4 rotors
Bluetooth version5.2
Maximum tilt angle40 °
Maximum ascent speed5 m/s
Maximum descent speed3.5 m/s
Maximum weight capacity- kg
Maximum wind resistance10.7 m/s
Vertical hover accuracy0.3 m
Horizontal hover accuracy0.1 m
Maximum operating distance10000 m
Number of propeller blades2
Maximum pitch angular velocity250 °/sec
Megapixel12 MP
Sensor typeCMOS
Digital zoom4 x
Video resolutions1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate60 fps
Optical sensor size1/1.3 \
Camera shutter speed1/8000-2 s
Supported video modes720p
Supported file systemsFAT32, exFAT
Angular vibration range-0.01 - 0.01 °
Image formats supportedDNG, JPG
Maximum aperture number1.7
Video formats supportedH.264
Maximum image resolution4000 x 3000 pixels
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle82.1 °
Bitrate at maximum video resolution100 Mbit/s
Built-in processor-
Compatible memory cardsMicroSD (TransFlash), MicroSDXC
Maximum memory card size512 GB
Flight modesFailsafe mode
Moving control functionsBackward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity1
Operating frequency2400-24835, 5725-5850 MHz
Maximum device width86 mm
Charging time64 min
Operating time38 min
Battery voltage7.38 V
Battery capacity2453 mAh
Transmitter battery capacity5200 mAh
Cables includedLightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth362 mm
Width251 mm
Height72 mm
Weight248 g
