dji Mini 3 User Manual

DJI Mini 3
User Manual
8
©
2022 DJI All Rights Reserved.
Activating the DJI Mini 3 Aircraft
DJI Mini 3 requires activation before first use. After powering on the aircraft and remote
controller, follow the on-screen prompts to activate DJI Mini 3 using DJI Fly. An internet
connection is required for activation.
Binding the Aircraft and Remote Controller
After activation, the aircraft is bound to the remote controller automatically. If automatic
binding fails, follow the on-screen prompts on DJI Fly to bind the aircraft and remote controller
for optimal warranty services.
Updating Firmware
A prompt will appear in DJI Fly when new firmware is available. Update the firmware whenever
prompted to ensure optimal user experience.
Diagram
Aircraft
1. Gimbal and Camera
2. Propellers
3. Aircraft Status LEDs
4. Battery Buckles
5. Downward Vision System
6. Infrared Sensing System
7. Motors
8. Landing Gears (Built-in antennas)
9. Battery Level LEDs
10. Power Button
11. USB-C Port
12. microSD Card Slot
13. Intelligent Flight Battery
1
11
2
7
12
8
13
9
5
10
4
3
6

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
