DJI Mini 3
User Manual
14
©
2022 DJI All Rights Reserved.
QuickTransfer
DJI Mini 3 can connect directly to mobile devices via Wi-Fi, enabling users to download photos
and videos from the aircraft to the mobile device through DJI Fly without using the DJI RC-N1
remote controller.
Users can enjoy faster and more convenient downloads with a transmission rate of up to 25 MB/s.
Usage
Method 1: mobile device is not connected to the DJI RC-N1 remote controller.
1. Power on the aircraft and wait until the self-diagnostic tests of the aircraft are complete.
Quickly press the power button three times to switch to QuickTransfer mode. The aircraft
status LEDs will blink blue once switching is successful.
2. Make sure Bluetooth and Wi-Fi are enabled on the mobile device. Launch DJI Fly and a
prompt will appear to connect to the aircraft.
3. Tap Connect. Once successfully connected, the files on the aircraft can be accessed and
downloaded at high speed. Note that when connecting the mobile device to the aircraft for
the first time, you need to press and hold the power button for two seconds to confirm.
Method 2: mobile device is connected to the DJI RC-N1 remote controller
1. Make sure that the aircraft is connected to the mobile device via the DJI RC-N1 remote
controller and the motors have not started.
2. Enable Bluetooth and Wi-Fi on the mobile device.
3. Launch DJI Fly, enter playback, and tap in the upper right corner. Switch to QuickTransfer
mode by following the prompts in DJI Fly. Download the files on the aircraft at high speed
once switching is complete.
The maximum download rate can only be achieved in countries and regions where
the 5.8 GHz frequency is permitted by laws and regulations, when using devices that
support 5.8 GHz frequency band and Wi-Fi connection, and in an environment without
interference or obstruction. If 5.8 GHz is not allowed by local regulations (such as in
Japan), or the mobile device of the user does not support the 5.8 GHz frequency band,
or the environment has severe interference, then QuickTransfer will use the 2.4 GHz
frequency band and its maximum download rate will reduce to 6 MB/s.
Make sure that Bluetooth, Wi-Fi, and location services are enabled on the mobile
device before using QuickTransfer.
When using QuickTransfer, it is not necessary to enter the Wi-Fi password on the
settings page of the mobile device in order to connect. Launch DJI Fly and a prompt
will appear to connect the aircraft.
Use QuickTransfer in an unobstructed environment with no interference and stay
away from sources of interference such as wireless routers, Bluetooth speakers, or
headphones.

Other manuals for dji Mini 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Mini 3 and is the answer not in the manual?

dji Mini 3 Specifications

General IconGeneral
TypeQuadcopter
FoldableYes
CertificationFCC
Product colorGray
Construction typeReady-to-fly (RTF)
Maximum speed10.55 m/s
Number of axis3
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors4 rotors
Bluetooth version5.2
Maximum tilt angle40 °
Maximum ascent speed5 m/s
Maximum descent speed3.5 m/s
Maximum weight capacity- kg
Maximum wind resistance10.7 m/s
Vertical hover accuracy0.3 m
Horizontal hover accuracy0.1 m
Maximum operating distance10000 m
Number of propeller blades2
Maximum pitch angular velocity250 °/sec
Megapixel12 MP
Sensor typeCMOS
Digital zoom4 x
Video resolutions1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate60 fps
Optical sensor size1/1.3 \
Camera shutter speed1/8000-2 s
Supported video modes720p
Supported file systemsFAT32, exFAT
Angular vibration range-0.01 - 0.01 °
Image formats supportedDNG, JPG
Maximum aperture number1.7
Video formats supportedH.264
Maximum image resolution4000 x 3000 pixels
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle82.1 °
Bitrate at maximum video resolution100 Mbit/s
Built-in processor-
Compatible memory cardsMicroSD (TransFlash), MicroSDXC
Maximum memory card size512 GB
Flight modesFailsafe mode
Moving control functionsBackward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity1
Operating frequency2400-24835, 5725-5850 MHz
Maximum device width86 mm
Charging time64 min
Operating time38 min
Battery voltage7.38 V
Battery capacity2453 mAh
Transmitter battery capacity5200 mAh
Cables includedLightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth362 mm
Width251 mm
Height72 mm
Weight248 g
Battery weight80.5 g
