dji Mini 3 User Manual

DJI Mini 3
User Manual
47
©
2022 DJI All Rights Reserved.
Camera View
1. Flight Mode
N Mode: Displays the current flight mode.
2. System Status Bar
In Flight: Indicates the aircraft flight status and displays various warning messages. Tap to
view more information when a warning prompt appears.
3. Battery Information
80
24'17"
: Displays the current battery level and remaining flight time.
4. Video Downlink Signal Strength
RC
: Displays the video downlink signal strength between the aircraft and the remote
controller.
5. GNSS Status
20
: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The
Home Point can be updated when the icon is white, which indicates the GNSS signal is
strong.
6. System Settings
: System settings provide information about safety, control, the camera, and
transmission.
•
Safety
RTH: Tap to set the Return to Home Altitude and update the Home Point.
Flight Protection: Tap to set the max altitude and the max distance for flights.
Sensors: Tap to view the IMU and compass statuses and start calibration if necessary.
1 2 3 4 5 6
14151617
18
19
10
11
8
9
7
12
13

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
