dji Mini 3 User Manual

32
©
2022 DJI All Rights Reserved.
Remote Controller
DJI RC
When used with DJI Mini 3, DJI RC remote controller features OcuSync 2.0 video transmission,
works at bo
th 2.4 GHz and 5.8 GHz frequency bands. It is capable of selecting the best
transmission channel automatically and can transmit 720p 30fps HD live view from the aircraft
to the remote controller at a distance of up to 10 km (6 mi) (compliant with FCC standards, and
measured in a wide open area without interference).
The DJI RC is also equipped with a 5.5-in touchscreen (1920×1080 pixel resolution) and a wide
range of controls and customizable buttons, enabling users to easily control the aircraft and
remotely change the aircraft settings. The built-in 5200 mAh battery with a power of 18.72 Wh
provides the remote controller with a maximum operating time of four hours. The DJI RC comes
with many other functions such as Wi-Fi connection, built-in GNSS (GPS+BeiDou+Galileo),
Bluetooth, built-in speakers, detachable control sticks, and microSD storage.
Using the Remote Controller
Powering On/Off
Press the power button once to check the current battery level.
Press once then press again and hold to power the remote controller on or off.
Charging the Battery
Use a USB-C cable to connect a USB charger to the USB-C port of the remote controller. The
battery can be fully charged in about 1 hour and 30 minutes with a maximum charging power
of 15 W (5V/3A).
•
It is recommended to use a USB Power Delivery charger.

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
