dji Mini 3 User Manual

DJI Mini 3
User Manual
33
©
2022 DJI All Rights Reserved.
Controlling the Aircraft
The control sticks control the aircraft’s orientation (pan), forward/backward movement (pitch),
altitude (throttle), and left/right movement (roll). The control stick mode determines the
function of each control stick movement. Three preprogrammed modes (Mode 1, Mode 2, and
Mode 3) are available and custom modes can be configured in DJI Fly.
Controlling the Gimbal and Camera
Focus/Shutter Button: Press halfway down to auto-
focus and press all the way down to take a photo.
Record Button: Press once to start or stop recording.
Camera Control Dial: Adjust the zoom.
Gimbal Dial: Control the tilt of the gimbal.
Gimbal
Dial
Record Button
Camera
Control
Dial
Focus/Shutter Button
Right StickLeft Stick
Turn RightTurn Left
UP
Down
RightLeft
UP
Down
Turn RightTurn Left
RightLeft
Forward
Backward
Left Stick Right Stick
Forward
Backward
Right Stick
UP
Down
Forward
Backward
Left Stick
Turn RightTurn Left
RightLeft
Mode 1
Mode
2
Mode
3

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
