dji Mini 3 User Manual

DJI Mini 3
User Manual
19
©
2022 DJI All Rights Reserved.
Intelligent Flight Mode
QuickShots
QuickShots shooting modes include Dronie, Rocket, Circle, Helix, and Boomerang. DJI Mini 3
records according to the selected shooting mode and automatically generates a short video.
The video can be viewed, edited, or shared to social media from playback.
Dronie: The aircraft flies backward and ascends with the camera locked on the subject.
Rocket: The aircraft ascends with the camera pointing downward.
Circle: The aircraft circles around the subject.
Helix: The aircraft ascends and spirals around the subject.
Boomerang: The aircraft flies around the subject in an oval path, ascending as it flies
away from its starting point and descending as it flies back. The starting point of the
aircraft forms one end of the long axis of the oval, while the other end of its long axis is
at the opposite side of the subject from the starting point. Make sure there is sufficient
space when using Boomerang. Allow a radius of at least 99 ft (30 m) around the aircraft
and allow at least 33 ft (10 m) above the aircraft.
Using QuickShots
1. Make sure that the Intelligent Flight Battery is sufficiently charged. Take off and hover at
least 6.6 ft (2 m) above the ground.
2. In DJI Fly, tap the shooting mode icon to select QuickShots and follow the prompts. Make
sure that you understand how to use the shooting mode and that there are no obstacles in
the surrounding area.
2 m

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
