Aircraft Status Indicator
DJI Mini 3 has two aircraft status indicators.
Aircraft Status Indicator
Aircraft Status Indicator
Refer to the table below for more information about the aircraft status indicators.
Aircraft Status Indicator Descriptions
Normal States
Blinks purple slowly Warming up
Alternating red, green and yellow
Powering on and performing self-diagnostic
tests
Blinks green slowly GNSS enabled
×2 Periodically blinks green twice Downward Vision System enabled
Blinks yellow slowly
GNSS and Downward Vision System
disabled (ATTI mode enabled)
Blinks blue slowly
Switching between Wi-Fi connection and
OcuSync 2.0 video transmission connection
×2 Periodically blinks blue twice
Switched to Wi-Fi connection and waiting to
connect to mobile device
—— Solid blue
Switched to Wi-Fi connection and connected
to mobile device
Blinks blue quickly
Switched to Wi-Fi connection and
downloading at high speed
—— Solid red Failed to switch to Wi-Fi connection
Blinks red slowly ESC is beeping while using Find My Drone
Warning States
Blinks yellow quickly Remote controller signal lost
Blinks red slowly Low battery
Blinks red quickly Critically low battery
Periodically blinks red IMU error
—— Solid red Critical error
Blinks red and yellow alternately Compass calibration required

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
