Page #32 background imageLoading...
Page #32 background image
DJI Mini 3
User Manual
30
©
2022 DJI All Rights Reserved.
Camera
DJI Mini 3 uses a 1/1.3-in CMOS sensor. The aperture of the camera is F1.7 and shoots from 1 m
to infinity.
The DJI Mini 3 camera can take 12MP stills and supports shooting modes such as Single, AEB,
Timed Shot and Panorama. It also supports recording 4K videos.
Make sure the temperature and humidity are suitable for the camera during use and
storage.
Use a lens cleanser to clean the lens to avoid damage or poor image quality.
DO NOT block any ventilation holes on the camera as the heat generated may damage
the device and injure the user.
Storing Photos and Videos
DJI Mini 3 supports the use of a microSD card to store your photos and videos. A microSD card
with a UHS-I Speed Grade 3 rating or above is required due to the fast read and write speeds
necessary for high-resolution video data. Refer to the Specifications for more information about
recommended microSD cards.
Without a microSD card inserted into the aircraft microSD card slot:
When using the DJI RC-N1 remote controller, the user can still capture single photos or record
720p videos. The file will be stored on the mobile device.
When using the DJI RC remote controller, the user cannot capture photos or record videos.
Insert a recommended microSD card into the aircraft microSD card slot in advance.
DO NOT remove the microSD card from the aircraft while it is powered on, or the
microSD card may be damaged.
Check camera settings before use to ensure they are configured correctly.
Before shooting important photos or videos, shoot a few images to test whether the
camera is operating correctly.
Photos or videos cannot be transferred from the microSD card in the aircraft using DJI
Fly if the aircraft is powered off.
Make sure to power off the aircraft correctly. Otherwise, the camera parameters will
not be saved and any recorded videos may be affected. DJI is not responsible for any
loss caused by an image or video recorded in a way that is not machine-readable.

Other manuals for dji Mini 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Mini 3 and is the answer not in the manual?

dji Mini 3 Specifications

General IconGeneral
TypeQuadcopter
FoldableYes
CertificationFCC
Product colorGray
Construction typeReady-to-fly (RTF)
Maximum speed10.55 m/s
Number of axis3
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors4 rotors
Bluetooth version5.2
Maximum tilt angle40 °
Maximum ascent speed5 m/s
Maximum descent speed3.5 m/s
Maximum weight capacity- kg
Maximum wind resistance10.7 m/s
Vertical hover accuracy0.3 m
Horizontal hover accuracy0.1 m
Maximum operating distance10000 m
Number of propeller blades2
Maximum pitch angular velocity250 °/sec
Megapixel12 MP
Sensor typeCMOS
Digital zoom4 x
Video resolutions1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate60 fps
Optical sensor size1/1.3 \
Camera shutter speed1/8000-2 s
Supported video modes720p
Supported file systemsFAT32, exFAT
Angular vibration range-0.01 - 0.01 °
Image formats supportedDNG, JPG
Maximum aperture number1.7
Video formats supportedH.264
Maximum image resolution4000 x 3000 pixels
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle82.1 °
Bitrate at maximum video resolution100 Mbit/s
Built-in processor-
Compatible memory cardsMicroSD (TransFlash), MicroSDXC
Maximum memory card size512 GB
Flight modesFailsafe mode
Moving control functionsBackward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity1
Operating frequency2400-24835, 5725-5850 MHz
Maximum device width86 mm
Charging time64 min
Operating time38 min
Battery voltage7.38 V
Battery capacity2453 mAh
Transmitter battery capacity5200 mAh
Cables includedLightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth362 mm
Width251 mm
Height72 mm
Weight248 g
Battery weight80.5 g
