dji Mini 3 User Manual

DJI Mini 3
User Manual
39
©
2022 DJI All Rights Reserved.
2. System Settings
Tap to access system settings and configure the Bluetooth, volume, network, etc. You can
also view the Guide to learn more about the controls and status LEDs.
3. Shortcuts
: Tap to enable or disable Wi-Fi. Hold to enter settings and then connect to or add a Wi-
Fi network.
: Tap to enable or disable Bluetooth. Hold to enter settings and connect with nearby
Bluetooth devices.
: Tap to enable Airplane mode. Wi-Fi and Bluetooth will be disabled.
: Tap to turn off system notifications and disable all alerts.
: Tap to start recording the screen. The function will be available only after a microSD
card is inserted into the microSD slot on the remote controller.
: Tap to take a screenshot. The function will be available only after a microSD card is
inserted into the microSD slot on the remote controller.
4. Adjusting Brightness
Slide the bar to adjust the screen brightness.
5. Adjusting Volume
Slide the bar to adjust the volume.
Advanced Features
Calibrating the Compass
The compass may need to be calibrated after the remote controller is used in areas with
electromagnetic interference. A warning prompt will appear if the compass of the remote
controller requires calibration. Tap the warning prompt to start calibrating. In other cases,
follow the steps below to calibrate your remote controller.
1. Power on the remote controller, and enter Quick Settings.
2. Tap to enter system settings, scroll down and tap Compass.
3. Follow the on-screen instructions to calibrate the compass.
4. A prompt will be displayed when the calibration is successful.

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
