dji Mini 3 User Manual

DJI Mini 3
User Manual
58
©
2022 DJI All Rights Reserved.
Max Angular Velocity
S Mode: 130°/s by default (the adjustable range on DJI Fly is 20-
250°/s)
N Mode: 75°/s by default (the adjustable range on DJI Fly is 20-
120°/s)
C Mode: 30°/s by default (the adjustable range on DJI Fly is 20-
60°/s)
Operating Temperature
GNSS
Hovering Accuracy Range
-10° to 40° C (14° to 104° F)
GPS + GLONASS + Galileo
Vertical: Vision Positioning: ±0.1 m; GNSS Positioning: ±0.5 m
Horizontal: Vision Positioning: ±0.3 m; GNSS Positioning: ±1.5 m
Transmission
Video Transmission System O2
Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Wi-Fi
Protocol 802.11 a/b/g/n/ac
Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <19 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: <20 dBm(FCC/SRRC), <14 dBm(CE)
Bluetooth
Protocol Bluetooth 5.2
Operating Frequency 2.4000-2.4835 GHz
Transmitter Power (EIRP) <8 dBm
Gimbal
Mechanical Range
Tilt: -135° to +80°
Roll: -135° to +45°
Pan: -30° to +30°
Controllable Range
Tilt: -90° to +60°
Roll: 0° or -90° (Landscape or Portrait)
Stabilization 3-axis (tilt, roll, pan)
Max Control Speed (tilt) 100°/s
Angular Vibration Range ±0.01°
Sensing System
Downward Vision System Precision Hovering Range: 0.5 m to 10 m
Operating Environment
Non-reflective, discernible surfaces with diffuse reflectivity of
>20%, and adequate illuminance of >15 lux
Camera
Image Sensor 1/1.3" CMOS, Effective Pixels: 12 MP
Lens
FOV: 82.1°
Format Equivalent: 24 mm
Aperture: f/1.7
Shooting Range: 1 m to ∞
ISO
Video: 100-3200
Photo: 100-3200

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
