dji Mini 3 User Manual

DJI Mini 3
User Manual
60
©
2022 DJI All Rights Reserved.
General
Operating Temperature -10° to 40° C (14° to 104° F)
Battery Capacity 5,200 mAh
Battery Type Li-ion
Chemical System LiNiMnCoO2
Operating Current/Voltage
1200 mA@3.6 V (with Android device)
700 mA@3.6 V (with iOS device)
Supported Mobile Device
Size
180×86×10 mm (Height×Width×Thickness)
Supported USB Port Types Lightning, Micro USB (Type-B), USB-C
Max Battery Life
6 hours (without charging any mobile device)
4 hours (when charging a mobile device)
DJI RC Remote Controller
Transmission
Video Transmission System
When used with different aircraft hardware configurations,
the DJI RC Remote Controller will automatically select the
corresponding firmware version for updating. It supports the O2
transmission technology when linked with DJI Mini 3.
Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE)
Max Transmission Distance
(unobstructed, free of
interference)
10 km (FCC), 6 km (CE/SRRC/MIC)
Data is tested under different standards in open areas free
of interference. It only refers to the maximum, one-way flight
distance without considering Return to Home. Please pay
attention to RTH prompts in the DJI Fly app during actual flight.
Transmission Distance (in
common scenarios, under
FCC standard)
Strong interference (e.g., city center): 1.5-3 km
Moderate interference (e.g., suburbs, small towns): 3-6 km
No interference (e.g., rural areas, beaches): 6-10 km
Data is tested under FCC standard in open areas and with
different levels of interference. The data is for reference only.
Please pay attention to RTH prompts in the DJI Fly app during
actual flight.
Wi-Fi
Protocol 802.11a/b/g/n
Operating Frequency 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.1 GHz: <23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
Protocol Bluetooth 4.2
Operating Frequency 2.4000-2.4835 GHz
Transmitter Power (EIRP) <10 dBm

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
