Page #64 background imageLoading...
Page #64 background image
DJI Mini 3
User Manual
62
©
2022 DJI All Rights Reserved.
Intelligent Flight Battery Plus
Battery Capacity 3850 mAh
Standard Voltage 7.38 V
Max Charging Voltage 8.5 V
Battery Type Li-ion
Chemical System LiNiMnCoO2
Energy 28.4 Wh
Weight Approx. 121 g
Charging Temperature 5° to 40° C (41° to 104° F)
Charging Time
101 minutes (with the DJI 30W USB-C Charger and the battery
mounted to the aircraft)
78 minutes (with the DJI 30W USB-C Charger and the battery
inserted into the DJI Mini 3 Pro Two-Way Charging Hub)
Recommended Charger
DJI 30W USB-C Charger or other USB Power Delivery chargers (30
W)
When you charge the battery mounted to the aircraft or inserted
into the DJI Mini 3 Pro Two-Way Charging Hub, the maximum
charging power supported is 30 W.
Two-Way Charging Hub
Input USB-C: 5V 3A, 9V 3A, 12V 3A
Output USB: 5V 2A
Rated Power 30 W
Charging Type Charge three batteries in sequence
Charging Temperature 5° to 40° C (41° to 104° F)
Supported Batteries
DJI Mini 3 Pro Intelligent Flight Battery (BWX162-2453-7.38)
DJI Mini 3 Pro Intelligent Flight Battery Plus (BWX162-3850-7.38)
App
Name DJI Fly
Required Operating System iOS v11.0 or later; Android v7.0 or later
Storage
Supported microSD Cards for
aircraft
UHS-I Speed Grade 3 rating microSD card
Recommended microSD
Cards for aircraft
SanDisk Extreme 32GB V30 A1 microSDXC
SanDisk Extreme 64GB V30 A1 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme Pro 32GB V30 A1 microSDXC
Kingston Canvas Go!Plus 64GB V30 A2 microSDXC
Kingston Canvas Go!Plus 256GB V30 A2 microSDXC
Kingston Canvas React Plus 64GB V30 A1 microSDXC
Kingston Canvas React Plus 128GB V30 A1 microSDXC
Samsung Pro Plus 256GB V30 A2 microSDXC

Other manuals for dji Mini 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Mini 3 and is the answer not in the manual?

dji Mini 3 Specifications

General IconGeneral
TypeQuadcopter
FoldableYes
CertificationFCC
Product colorGray
Construction typeReady-to-fly (RTF)
Maximum speed10.55 m/s
Number of axis3
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors4 rotors
Bluetooth version5.2
Maximum tilt angle40 °
Maximum ascent speed5 m/s
Maximum descent speed3.5 m/s
Maximum weight capacity- kg
Maximum wind resistance10.7 m/s
Vertical hover accuracy0.3 m
Horizontal hover accuracy0.1 m
Maximum operating distance10000 m
Number of propeller blades2
Maximum pitch angular velocity250 °/sec
Megapixel12 MP
Sensor typeCMOS
Digital zoom4 x
Video resolutions1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate60 fps
Optical sensor size1/1.3 \
Camera shutter speed1/8000-2 s
Supported video modes720p
Supported file systemsFAT32, exFAT
Angular vibration range-0.01 - 0.01 °
Image formats supportedDNG, JPG
Maximum aperture number1.7
Video formats supportedH.264
Maximum image resolution4000 x 3000 pixels
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle82.1 °
Bitrate at maximum video resolution100 Mbit/s
Built-in processor-
Compatible memory cardsMicroSD (TransFlash), MicroSDXC
Maximum memory card size512 GB
Flight modesFailsafe mode
Moving control functionsBackward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity1
Operating frequency2400-24835, 5725-5850 MHz
Maximum device width86 mm
Charging time64 min
Operating time38 min
Battery voltage7.38 V
Battery capacity2453 mAh
Transmitter battery capacity5200 mAh
Cables includedLightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth362 mm
Width251 mm
Height72 mm
Weight248 g
Battery weight80.5 g
