dji Mini 3 User Manual

DJI Mini 3
User Manual
6
©
2022 DJI All Rights Reserved.
2. All Intelligent Flight Batteries are in hibernation mode before shipment to ensure safety.
Connect a USB charger to the USB-C port on the aircraft to charge and activate the Intelligent
Flight Battery for the first time.
3. Unfold the rear arms, followed by the front arms, and then all of the propeller blades.
•
It is recommended to use the DJI 30W USB-C Charger or other USB Power Delivery
chargers.
•
The maximum charge voltage for the aircraft charging port is 15 V.
•
Make sure the gimbal protector is removed and all arms are unfolded before
powering on the aircraft. Otherwise, it may affect the aircraft self-diagnostics.
•
Attach the gimbal protector when the aircraft is not in use. Ensure all arms are folded
before reattaching the gimbal protector. First rotate the camera to make it horizontal
and forward-facing
①
, then insert the latch on the upper part of the protector onto
the opening on the aircraft
②
, and insert the two locating pins into the holes at the
bottom of the aircraft
③
.
1
2
3

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
