Page #20 background imageLoading...
Page #20 background image
18
CHS
视频格式 MOVMP4
录像分辨率 H.2644K3840×2160 30p
云台
稳定系统
3
轴(俯仰,横滚,平移)
角度抖动量
±0.01°
安装方式
DJI SKYPORT
快拆
可控转动范围 俯仰:
-120°
+30°
,平移:
±320°
工作模式 跟随
/
自由
/
回中
数据存储
原始数据存储 照片 /IMU/ 点云数据 /GNSS 数据 / 标定文件
支持的存储卡类型 microSD 卡;最大支持 256 GB 容量,顺序写入速度 ≥50 MB/s, 传输速
度达到 UHS-I Speed Grade 3,请使用指定推荐用卡。
推荐存储卡类型 ** SanDisk Extreme 128GB UHS-I Speed Grade 3
SanDisk Extreme 64GB UHS-I Speed Grade 3
SanDisk Extreme 32GB UHS-I Speed Grade 3
SanDisk Extreme 16GB UHS-I Speed Grade 3
Lexar 1066x 128GB U3
Samsung EVO Plus 128GB
后处理软件
支持软件 大疆智图
数据格式 大疆智图支持标准格式点云模型导出:
点云格式:
PNTS/LAS/PLY/PCD/S3MB
格式
* 精度由大疆实验室在以下条件测得:L1 负载上电预热 5 分钟,使用 DJI Pilot 航线任务为建图航拍(开
启标定飞行),RTK 状态为 FIX,任务相对高度为 50 m、飞行速度为 10 m/s、云台俯仰为 -90°、航线
中每个直线段不超过 1000 m,使用 DJI Terra 进行后处理。
** 后续可能更新,请访问 DJI 官网进行查询。
内容如有更新,恕不另行通知。
您可以在 DJI 官方网站查询最新版本
http://www.dji.com/zenmuse-l1
DJI 是大疆创新的商标。
Copyright © 2021 大疆创新 版权所有

Other manuals for dji ZENMUSE L1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji ZENMUSE L1 and is the answer not in the manual?

dji ZENMUSE L1 Specifications

General IconGeneral
Product typeCamera module
CompatibilityMatrice 300 RTK
Product colorBlack
Brand compatibilityDJI
Operating temperature (T-T)-20 - 50 °C
Megapixel20 MP
Sensor typeCMOS
Maximum frame rate30 fps
Camera shutter speed1/8000 - 8 s
ISO sensitivity (max)12800
ISO sensitivity (min)100
Image formats supportedJPEG
Video formats supportedH.264, MOV, MP4
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle95 °
Weight and Dimensions IconWeight and Dimensions
Depth169 mm
Width110 mm
Height152 mm
Weight930 g
