CellCom‑LTE

Programming and Installation Guide Digital Monitoring Products

35

Bosch Control Panel Option Bus to CellCom‑LTE for Reduced Noise Disturbance

Option Bus

CellCom-LTE-V

PROG

+12 G Z1 Z2 Z4-Z4+GZ3 RTO2O1

RB

Control Panel

R

B

G

Y

Figure 19: Bosch Control Panel Option Bus to CellCom-LTE
