eBox-3300
4
About Embedded CPU Board
SYSTEM SPECIFICATION
CPU
Vortex86DX SoC (System on Chip)
Main Memory
256MB DDR2
BIOS
AMI BIOS
VGA
XGI Z9S with 32MB DDR2
Resolution up to 1,280x1,024 High Colors
Audio
Mic In, Line Out
Keyboard and Mouse
PS/2 Keyboard and Mouse
On-Board IDE
Enhanced IDE interface, 44-pin box
header x 1
Peripheral
1. USB V2.0 (host) x 3
2. Audio (Mic In, Line Out)
3. Type I/II CF Slot and Micro-SD
4. Serial ports x 2 (available for eBox-
3300-JSK)
5. Mini PCI socket x1 (available for eBox-
3300-M and 3300-JSK)
6. 2
nd
RJ-45 LAN (only available on
eBox-3300-L2)
Dimension & Weight
115 x 115 x 35 mm / 505g
Operating System
Suitable for:
Windows XP
Windows XP Embedded
Windows Embedded CE
Linux
3
