8 LCD Keypad Installation Guide
Programming Keypad Options
Kpd Kpd
Opt diag StOp
Keypad Options (KPD OPT)
To program keypad options, press the left Select key under
KPD OPT.
CUrrent Keypad
addreSS: 01
Keypad Address
Set the keypad address from 01 to 08 with the XT30, XT50,
XR100 or XR150 and 01 to 16 with the XR500 Series or
XR350/XR550 Series. The factory default address is set at
01. To change the current address, press any Select key and
enter the new address. It is not necessary to enter a leading
zero for addresses 01 to 09.
Keypad MOde:
*SUp UnSUp
Keypad Mode
Congure the keypad for either Supervised or Unsupervised
operation. Keypads with zones connected to them must be
supervised and cannot share addresses with other keypads.
Unsupervised keypads can operate with other unsupervised
keypads sharing the same address. Zones cannot be used on
unsupervised keypads. To change the current setting, press
the Select key under SUP or UNSUP. An asterisk appears next
to the selected option.
Note: Unsupervised addresses cannot be used when Device
Fail Output has a programmed value other than zero.
deFaULt Keypad
MSg:
Default Keypad Message
Enter a custom message of up to 16 characters to appear on
the keypad display top line whenever that line is not used for
any other purpose. Press any Select key to clear the current
message and enter a new custom display.
arM paniC KeyS:
*pn *eM *Fi
Arm Panic Keys
Use this option to congure the top row Select keys as
2-button Panic keys. To enable or disable a Panic, press the
Select key under the appropriate display: PN (Panic), EM
(Emergency), and FI (Fire). Once the panic is enabled, an
asterisk displays next to the description. Refer to the Panic
Key Options section earlier in this document.
7/0 paniC
enabLe: nO yeS
7/0 Panic
Select YES to congure the 7 and 0 keys as a 2-button Panic
keys. To disable the option, select NO. Default is NO. Refer
to the Panic Key Options section earlier in this document.
aCtiVate zOne 2
bypaSS: nO yeS
Zone 2 Bypass (7073/7073A/7173 only)
Select YES to enable the Bypass option on zone 2 as
described earlier in this document. This zone provides the
Bypass for door contacts. This zone must be programmed
into the panel.
