27
END USER TRAINING
This section covers 7063/A, 7073/A, 7163, and 7173 keypads and contains three sections:
• Keypad Arming and Disarming
• Keypad Access Control
• Keypad Entry Delay
All of the examples displayed assume that CLOSING CODE is YES in panel programming.
Figures 11 through 14 show the user presenting a card to the keypad. When an external
reader is connected to a 7073/A and a 7173 keypad, the user presents a card to the reader
rather than to the keypad.
Keypad Arming and Disarming
Area System Arming and Disarming
1. Press CMD until the keypad displays ARM DISARM.
2. Press the select key under the preferred option.
3. The keypad displays ENTER CODE: -. The user presents their card to the reader.
Once validated by the system, all areas assigned to that code arm or disarm
automatically and the 7073/A and 7173 keypad door strike relay activates. See Figure 11.
Figure 11: Area Arming and Disarming
ABC SECURITY
ARM DISARM
ABC SECURITY
ENTER CODE: –
ABC SECURITY
ALL? NO YES
Select NO to arm or disarm individual areas.
Select YES, or simply wait, to automatically arm or disarm all areas for which you are authorized.
