21
Card Options (7063/A, 7073/A, 7163, 7173)
Select DMP to indicate the reader sends a 26-bit DMP data
string. To save the DMP option, press the left top row select key
under DMP. Default is DMP. Select CUSTOM if using a non-DMP
credential by pressing the right top row select key.
Wiegand Code Length (7063/A, 7073/A, 7163, 7173)
When using a custom credential, enter the total number of bits
to be received in Wiegand code including parity bits. Press any
top row select key to enter a number between 0-255 to equal
the number of bits. Default is 26 bits. An access card contains
data bits for a site code, a user code, and start/stop/parity bits.
The starting position location and code length must be
determined and programmed into the keypad. See Figure 10.
CARD OPTIONS
DMP CUSTOM
WIEGAND CODE
LENGTH: 26
01110101101101010001100111
First Bit
Received
Position = 0
Site Code
Position = 1
Length = 8
User Code
Position = 9
Length = 16
Last Bit
Received
Position = 25
In this example the Wiegand Code Length = 26 bits.
Figure 10: Data Stream Bit Location Example
Installer Options
