DNT UltraZoom PRO - Part Names & Functions

36 37
6
■ Parts Names & Functions
No. Functions No. Functions
1 Micro-SD card slot 8 Height adjustment
2 Video-out 9 Capture
3 HDMI-out 10 5-inch IPS LCD display
4 Focus tube 11 Dimmer for LEDs in the lens tube
5 Polarizer wheel 12 Digital zoom
6 Charging indicator 13 Dimmer for LEDs in the platform
7 LED light for slice 14 USB/DC-in
15. Power on/off
16. Setup/Settings
17. Up
18. Confirm
19. Down
20. Mode (Photo/Video/Playback)
