5. Technical data
5.2 Multifunction safety module BI 5910
Radio
Conformity: ETS 300 220
Aerial: 1/4 aerial, plug in as accessory
Frequency: 64 programmable frequencies 433.1 … 434.675 MHz
Sensitivity: < -100 dBm
Nominal voltage U
N
: DC 24 V
Voltage range: at max. 5 % residual ripple: 0,85... 1,15 U
N
Nominal consumption: max. 120 mA (Semiconductor outputs not connected)
Control voltage on
S11, S13, S21, S23, S31,
S33,48, 58: DC 23 V at U
N
Control current on
S12, S14, S22, S24, S32,
S34, S42: each 4,5 mA at U
N
Min. voltage at terminals
S12, S14, S22, S24, S32
S34, S42: DC 16 V
Max. voltage for
inactive terminals: S12, S14,
S22, S24, S32, S34, S42: DC 9 V
Max. Inputvoltage on S12,
S14, S22, S24, S32, S34, S42: DC 30 V
