DOLD BI 5910 - Manual Start and Reset; Auto Start

26
26
2.6 Manual start and reset
The start button on terminal S42 as well as
the green button on the remote control are
used for manual start and to reset the safety
module. The maximum activation time of the
start button is 3 sec. If the button is activated
longer the unit does not start.
When switching on the BI5910 or when a
failure occurs no start button must be
activated.
2.7 Auto start
The e-stop function or light curtains on S11
to S14 and S21 to S24 can be configured
for automatic start. I.e. the BI 5910 activates
the safety output relays as soon as the
safety function is fulfilled (e.g. e-stop button
is reset).
If the remote control is placed back on the
charger with activated e-stop the safety
module will not be activated automatically
on closed control contacts.
