3. Remote control
RE 5910
3.1 Type and specification
of push buttons
1
R
1
2
R
1
1,2
The remote control is available with 5
different types of buttons:
1-position push button
(BPSV)
2-position push button
(BPDV)
rotational switch with
2 positions (COM2)
rotational switch with
3 positions (COM3)
rotational switch
auto resetting
with 3 positions (COM3R)
The location of the buttons is numbered to
identify it as described in appendix A.
R
1
2
