Appendix
B Front of multifunction safety module BI 5910 with radio control
position marking
of terminal blocks
Removable front plate
2 green LEDs:
Safety relays energised
White status LEDs
run 1 and run 2
Red LED receiver error
status of BI 5910
BNC-connector for aerial
Green LED reception
quality of radio signal
Removable terminal block
