DOLD BI 5910 - Page 47

47
47
2.10.1 Function diagrams
Rotational switches B=2:
- Protective devices on inputs S11-S14 and S21-S24 always active, auto start
- Remote control is active, when the control contacts on S32 or S 34 open.
-Reset of remote e-stop with remote start button (+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
2.10.1 Function diagrams
Rotational switches B=2:
- Protective devices on inputs S11-S14 and S21-S24 always active, auto start
- Remote control is active, when the control contacts on S32 or S 34 open.
-Reset of remote e-stop with remote start button (+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
