Rotational switches B=4:
- Protective devices on inputs S11-S14 and S21-S24 always active,
manual start
- Remote control is active, when the control contacts on S32 or S 34 open.
- Reset of all failures with start button on S42 or with remote start button
(+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
2.10.1 Function diagrams
Rotational switches B=4:
- Protective devices on inputs S11-S14 and S21-S24 always active,
manual start
- Remote control is active, when the control contacts on S32 or S 34 open.
- Reset of all failures with start button on S42 or with remote start button
(+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
