2.11 Operating modes 8 – 9 monitored zone access
5. After elapse of the bridging time the pro-
tection is activated again. This state is
indicated by the white LED and the out-
put 58 being continuously on.
6. To leave the protected area the operator
must activate and de-activate the inside
entry release button (S33-S34) and the
green start button on the remote control
at the same time. From this moment the
light barrier or safety gate function is
disabled for the adjusted time. During this
period the white LED run2 and the output
58 flash slowly and symmetric to indicate
the disabled protection.
7. Outside the protected area the operator
places the remote control back into the
chargaer and the control contact (S31-
S32) closes. Latest after 1 sec the remote
control must goes into inactive state, if not
the safety relays will disconnect and the
white LED run2 and output 58 go off.
The disabling time and the max time to
reset the remote control after taking from
the charger are adjusted with the
rotational switches A. Both buttons for
entry release inside and outside are
connected in parallel to terminals S33-
S34.
